- Booting [Dell T5500]
- Display [Nvidia Quadro 4000]
- Ethernet [Broadcom 5754 Gigabit Controller]
- Sound [ADI 198x Integrated HD Audio]
- USB Ports (front & back)
- all HDDs (SAS are also being recognized)
- Sleep
If something isnt listed here I have just not tested it yet!
Issues?
- Native NVRAM [It seems the nvidia driver gets loaded, but in macos I can't check NVIDIA Web Driver, it always uses OS X Default Graphics Driver. Tried to fix it with this thread to 'Problem 6', but it didnt worked. - not critical as drivers are working and resolution is fine ]
- SAS HDD is recognized as 'external' -> Not possible to boot with Clover
- hot graphics card (should be a generall issue with the Quadro 4000, but on MacOS it is maybe a bit more worse)
- 2 graphic cards will work, but there will be issues like longer boot, display random turn off and wont wake up
My procedure
BIOS Customization:
Bios Version: A16 (A06 tested also)
- Activated Intel Virtualization Technology
- Activated AHCI for SATA
Installation:
Booted the Legacy Clover Stick with
nv_disable=1 kext-dev-mode=1 dart=0 (PCIRootUID=4)The installation then went fine and I finished it without issues. I figured out that I could install MacOS on my SAS HDD but then couldnt booted it up (was recognized as 'external' hdd), so I went with installing it on a WesternDigital Black HDD.
Post Installation:
Booted it up again with the same boot args in Clover 4003, then I've downloaded the following things with another PC and copyied it with an NTFS formatted USB drive to my Hackintosh.
You can use my config.plst if you want to.
Multibeast:
Choosed FakeSMC and Clover. System Definition: MacPro 5,1
Other:
Ethernet/LAN: download attached modified BCM5722D.kext.zip and inject with Kext Utility If it doesn't work do the following:
edit the Info.plist as follows:
sudo vi /System/Library/Extensions/IONetworkingFamily.kext/Contents/PlugIns/BCM5722D.kext/Contents/Info.plist
I added an extra line to the dictionary containing the Device IDs:
<array>
<string>pci14e4,165a</string>
<string>pci14e4,167a</string>
<string>pci14e4,1672</string>
<string>pci14e4,167b</string>
<string>pci14e4,1673</string>
<string>pci14e4,1681</string>
<string>pci14e4,169b</string>
<string>pci14e4,1693</string>
<string>pci14e4,1712</string>
<string>pci14e4,1713</string>
</array>
The entry with pci14e4,1681 is what has to be added.
sudo vi /System/Library/Extensions/IONetworkingFamily.kext/Contents/PlugIns/BCM5722D.kext/Contents/Info.plist
I added an extra line to the dictionary containing the Device IDs:
<array>
<string>pci14e4,165a</string>
<string>pci14e4,167a</string>
<string>pci14e4,1672</string>
<string>pci14e4,167b</string>
<string>pci14e4,1673</string>
<string>pci14e4,1681</string>
<string>pci14e4,169b</string>
<string>pci14e4,1693</string>
<string>pci14e4,1712</string>
<string>pci14e4,1713</string>
</array>
The entry with pci14e4,1681 is what has to be added.
Sound: download attached AppleHDADisabler.kext 2.zip & VoodooHDA.kext V289 and inject with Kext Utility
(Optional: Update Clover to the latest version)
Graphics (Quadro 4000):
1. Download the Nvidia Custom Driver from NVIDIA (choose Quadro 4000 for Mac) or from tonymacx86.
2. After Installing (Don't reboot now!) the Custom Driver go to this thread to 'Problem 4' and choose they way you like to fix black screen with nvidia driver. I've choosed Method 3, but 2 will also work. 1 WILL NOT Work!
Now you can boot without nv_disable=1 and if you want you can use nvda_drv=1 instead.
Boot args:
nvda_drv=1 kext-dev-mode=1 dart=0 PCIRootUID=4
_______________________________________________________________
//Updating MacOS:
MacOS Updates tested & working:
10.12.2 -> 10.12.3 -> 10.12.4
1. Download the Update in the App Store
2. Reboot to install the MacOS Update (boot with nv_disable=1 !!)
3. Go to Settings -> Nvidia Manager & search for an update. Download & install it.
3. Go 'Graphics' in my thread and fix the black screen again
4. Reboot with nvda_drv=1 and the other boot args you used before
5. Enjoy the newest MacOS on your PC
********
Dual Boot pre installed Windows 10/Server2016 & this newly installed MacOS
1. Boot Windows 10 & enter this command: bcdboot C:Windows /s C: /f uefi
2. In MacOS mount the EFI partition with Clover Configurator (or any other programm)
3. Copy NTFS.efi into the /EFI/CLOVER/drivers64 & /drivers64UEFI folders.
3.5 [Optional*] Drag the entire 'Microsoft' folder inside the 'EFI' folder
4. [Optional*]Now take BOOTX64-win.efi from the Windows UEFI.zip mentioned above and drag that file into the 'BOOT' folder sitting inside underneath same 'EFI' folder.
* Optional because for me it worked without these steps.
Questens&Answers:
Q: Will my Xeon X5670, X5677 or other (same family) work?
A: Yes, tested by me. But be sure to give feedback under this post!
A: X5690, yes, tested by user
Thanks to / Credits:Ethernet: http://www.onedigit.co.uk/content/hackintosh-dell-t7500
